Controller Operation
AYC-Qx4 Family Installation and Programming Manual 37
5.8 Secured Intelligent Power Supply
Rosslare’s secured intelligent power supplies are designed for use with
Rosslare's secured standalone access control units, including the
AYC-Qx4 series. The AYC-Qx4 units are designed to operate indoors
and are installed within the secured premises. The units must be used
with one of Rosslare’s secured intelligent power supplies, which
provides Lock Strike output and REX input. The AYC-Qx4 and the
power supply communicate through a proprietary Rosslare protocol,
which provides a secure link between them. This in turn activates the
door lock.
Each power supply unit contains a speaker connection for all sounder
abilities.
For more information, see the
PS-x25x Installation Manual
.
5.9 Programming as a Controller
Programming is done solely via the unit's keypad driven Programming
Menu System. To reach the Programming Menu System, the unit
must first be put into Programming mode (see Section 5.9.1).
During the manufacturing process, certain codes and settings are pre-
programmed. These settings are the called the default factory
settings.
Table 4 shows the names of all the controller programming menus. It
also shows of all the default factory codes and settings for the units.
Table 4: Controller Programming Menu
Menu
No.
Menu Description Default
4
digits
5
digits
6
digits
4-8
digits
1 Changing Lock Strike Code 2580 25802 258025 25802580
2 Change Auxiliary Code 0852 08520 085208 08520852
3 Changing Program Code 1234 12341 123412 12341234
4 Changing Normal/Secure Code 3838 38383 383838 38383838
5 Changing Normal/Bypass Code N/A
