AYC-Qx4 family manual Page 15
5.2 Programming the AYC-Qx4 Series
Programming the AYC-Qx4 series is done solely via the unit's
keypad driven Programming Menu System. To reach the
Programming Menu System the AYC-Qx4 must first be placed into
Programming Mode. During the AYC-Qx4's manufacturing
process certain codes and settings are pre-programmed. These
settings are the called the "Default Factory Settings".
The table below shows the names of all the AYC-Qx4 Menus.
Programming Menu
Default Factory Settings are marked by a "*" sign.
Menu Description Default
1 Selecting Keypad Transmission Format
Single Key, 6-Bit Wiegand (Rosslare Format)
Single Key, 6-Bit Wiegand with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, 26-Bit Wiegand
1 to 5 Keys + Facility Code, 26-Bit Wiegand
6 Keys BCD and Parity Bits, 26-Bit Wiegand
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data
*
2 Selecting Card Transmission Format
26-Bit Wiegand
Clock & Data
Wiegand Card + PIN
*
3 Changing the Programming Code 1234
4 Changing the Facility Code 0
0 Return to Factory Default Settings
