Rosslare AYC-Q Series User Manual

Controller Functionality
AYC-Qx4 family manual Page 43
Quick Reference Guide for Auxiliary Mode Setting
Auxiliary
Mode
Auxiliary Input Function
Auxiliary Output
Activated by
Auxiliary
Relay
Auxiliary Settings
(in seconds)
0 AUX REX Valid code or AUX REX N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
1 Normal/Secure switch Valid code N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
2 Normal/Secure switch Star button (Å) N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
3 Normal/Secure switch Tamper event N.C. 01 to 99 Aux. relay release time
00 Aux. relay tamper activated
4 Normal/Secure switch Direct shunt N.O. 01 to 99 Shunt time
5 Door Monitor Shunt N.C. 01 to 99 Maximum shunt time
6 Door Monitor Forced door N.C. 01 to 99 Forced delay
7 Door Monitor Door ajar N.C. 01 to 99 Ajar delay
8 LED control – Green Valid code N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
9 LED control - Red Valid code N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
