Technical Specifications
AYC-Qx4 family manual Page 8
Specifications AYC-Q54B AYC-Q64B
Environmental Characteristics
Operating temp. range -22 to 150° F (-30 to 65° C)
Operating humidity 0 – 95% (non-condensing)
Outdoor usage Weather-resistant, meets IP-65, epoxy
potted, suitable for outdoor use
Mechanical
Size
(Height x Width x Depth)
4.72 x 3 x 0.827 inches
120 x 76 x21mm
Weight
1.05 lb (480gm)
*Measured using Rosslare proximity card (AT-14) or equivalent.
Range also depends on electrical environment and proximity to
metal.
2.1 Key Features
The key features for the AYC-Qx4 series are:
• Built-In Proximity Card Reader (125 KHz ASK Modulation)
(for 64 series only)
• Patented Blue backlit keypad
• Optical back tamper sensor and open controller tamper
output.
• Lockout feature on wrong entries (Keypad / Card
Tamper)
• Internal buzzer provides audible interface feedback
• Two status / programming Interface LEDs (tri-colored)
• Fully potted construction for outdoor use
• Comes with mounting template for easier installation
• Comes with an installation kit that includes a security
screw and a security screw tool
