Rosslare AYC-Q Series User Manual

Controller Functionality
AYC-Qx4 family manual Page 56
• The Mode LED will turn
green.
• The Door LED will turn
orange.
3) Enter the 3-digit user slot for code
assignment.
• The Mode LED will flash green.
4) Enter the assignment digit for the current user slot:
• 1 will activate the Lock Strike relay only deafult
• 2 will activate the Auxiliary relay only
• 3 will activate the Lock Strike and Auxiliary relays.
If the assignment code is valid,
the Mode indicator will stop
flashing.
The controller is now waiting for another slot number. Depress the
# key to move to the next slot or enter a new slot number. If you
do not wish to continue, depress the # key twice and the
controller will return to its normal mode.
Relay Code Assignment using Search Method
1) Enter the programming
mode.
2) Depress 9 to enter Menu 9.
• The Mode LED will turn green.
• The Door LED will turn
orange.
3) Enter 000 for user slot access.
? ? ?
9
0 0 0
Mode/Transmit
Door/Program
Green Oran
g
e
Mode/Transmit
Door/Pro
g
ram
Green Oran
g
e
Mode/Transmit
Door/Program
Green Oran
g
e
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Green Oran
g
e
