Keypad Programming Instructions
AY-T6350 Installation and Programming Manual 15
5. Keypad Programming Instructions
5.1 Programming Menu
Programming the reader is done via the unit's keypad driven
programming menu system. Table 2 shows the names of all the
programming menus. Default factory settings (certain pre-
programmed codes and settings) are marked by an asterisk (*).
Table 2: Programming Menu
Menu Description Default
1 Selecting Keypad Transmission Format
1 Single Key, Wiegand 6-Bit (Rosslare Format, Default)
2 Single Key, Wiegand 6-Bit with Nibble + Parity Bits
3 Single Key, Wiegand 8-Bit, Nibbles Complemented
4 4 Keys Binary + Facility Code, Wiegand 26-Bit
5 1 to 5 Keys + Facility Code, Wiegand 26-Bit
6 6 Keys BCD and Parity Bits, Wiegand 26-Bit
7 Single Key, 3x4 Matrix Keypad
8 1 to 8 Keys BCD, Clock & Data Single Key
*
2
Selecting
MIFARE Card Transmission Format
1 Wiegand 26-Bit (default)
2 Clock & Data
3 – Wiegand Card + PIN
4 Wiegand 26-Bit with Facility Code Output
5 Wiegand 32-Bit
6 Wiegand 32-Bit Reverse Output
7 Wiegand 34-Bit
8 Wiegand 40-Bit
*
3 Changing the Programming Code
1234
4 Changing the Facility Code
001
0 Return to Factory Default Settings
