Rotary SM30 User Manual

9
Mount Power Unit
Crimped Hose
Sleeve (Typical)
RIGHT SIDE VIEW
OF POWER UNIT
NP253
NP334
POWER UNIT
COLUMN
Elbow
Power Unit Hose
CAPACITY
30,000 LBS.
CAPACITY
30,0
00 LB
S.
Fill/Breather Cap
Fig. 16
Fig. 17
Place air valve bracket
on column bracket
before attaching motor.
Push nuts hold
bolts to brackets.
Use (4) 5/16"-18NC X 1 1/2" lg.
HHCS and Nuts.
On one bolt, place
(2) 5/16" Star Washers
PUSH TO
RELEASE
LATCHES
NP280
PUSH TO
RELEASE
LATCHES
NP280
