5.1) Performance data
Performance
graphs
Engine 912 A/F/UL
Performance graphs for stand. conditions (ISA)
5800 rpm
500040003000
0
10
20
30
40
50
kW
60
A
B
10
20
30
60
70
hp
80
50
40
Figure .1: Performance graphs 912 A/F/UL
A
max. engine output
B
power requirement of
propeller
5800 rpm500040003000
0
10
20
in.Hg
30
10
20
L/h
30
C
D
(2,64)
(5,28)
(Gal/h)
(7,93)
0
Figure .2: Values along propeller curve
C
manifold pressure
D
fuel consumption
