2.3.4 Other mounting accessories
Solar panel mounting rails
Solaris connection pipe ( 16 47 13) for
flat roof installation
Fig. 2-5 CON F (optional)
Solaris connection pipe ( 16 46 10) for
in-roof installation
Fig. 2-6 CON I (optional)
Solaris storage tank extension set ( 16 01 07):
for connecting two Sanicube Solaris storage tanks,
consisting of a return flow connection pipe and
feed connection pipe.
Fig. 2-7 CON SX (optional)
FIX-100 ( 16 42 24):
– Two mounting rails for a V21A solar panel
FIX-130 ( 16 42 25):
– Two mounting rails for a V26A solar panel
FIX-200 ( 16 42 26):
– Two mounting rails for one H26A solar panel or
two V21A solar panels
FIX-260 ( 16 42 27):
– Two mounting rails for two V26A solar panels
Fig. 2-8 Solar panel mounting rails
