3 x Installation
23
FA ROTEX Solaris - 08/2007
3.4.1 Installing the supporting structure for subsequent installation on the roof
Main dimensions of Solaris solar panel array for on-roof mounting
Tab. 3-1 Main dimensions of Solaris solar panel array for on-roof mounting
Instead of the mounting kit FIX-AD, the roof fixtures FIX-WD ( 1647 03) are used for corrugated roofs
and the fixtures FIX-BD ( 16 47 04) for trapezoidal roofs.
Number of solar panels 1 2 3 4 5
Measurement Dim. Dimensions in mm
Width of solar panel array
V21A
B
1100 2150 3250 4300 5400
V26A 1370 2740 4110 5480 6850
H26A 2150 4300 6450 8600 10750
Distance from roof duct H0 300 to 700
Height of solar panel array
V21A
h1
2000
V26A 2000
H26A 1300
Distance from lower solar panel edge to lower
mounting rail
Y0 230
Spacing of the mounting rails
V21A
Y1
1400 to 1600
V26A 1400 to 1600
H26A 800 to 1000
Distance from lower solar panel edge to lower edge
of the perforated plate of
roof mounting bracket
Y2 260 to 290
Max. distance from edge of solar panel array to the
first roof mounting bracket
X0 450
Spacing of the roof mounting brackets of a solar panel
V21A
X1
400 to 1000
V26A 400 to 1000
H26A —
Spacing of roof mounting brackets between two solar
panels
X2 300 to 900
Distance between solar panel array and the first solar
panel securing clip
A0 100 to 300
Spacing of the securing clips of a solar panel
V21A
A1
700 to 850
V26A 800 to 1100
H26A 120 to 1800
Spacing of the securing clips between two solar panels A2 200 to 500
Distance from solar panel edge to pipe coupling E0 approx. 60
Centre-to-centre distance of the solar panel couplings
V21A
E1
1879
V26A 1879
H26A 1185
Upper solar panel edge to solar panel sensor connection F 175
