Rottler SG9M - Chapter 6 Contents; Consumable Parts; Machine Parts

Machine Parts 2 SG9M Manual
Machine Parts
Consumable Parts
REFERENCE DESCRIPTION
SLEEVE R1 Spindle adapter replacement sleeve
BSW002
Diamond Wheel Cutting Bit Sharpener replacement Wheel (3.000" Diameter OD by
.375" ID)
PRW600PIN Replaceable Pins for PRW600 Pilot Removable wrench tool
PRW375PIN Replaceable Pins for PRW375 Pilot Removable wrench tool
PRW20PIN Replaceable Pins for PRW375 Pilot Removable wrench tool
VT-FP1562 Replacement Foam Pad for Round Vacuum Pad 1.562" diameter
VT-FP1875 Replacement Foam Pad for Round Vacuum Pad 1.875" diameter
VT-FP2125 Replacement Foam Pad for Round Vacuum Pad 2.125" diameter
VT-FP3125 Replacement Foam Pad for Round Vacuum Pad 3.125" diameter
VT-FP25X22 Replacement Foam Pad for Square Vacuum Pad 2.500" x 2.250" square
VT-FP31X20 Replacement Foam Pad for Square Vacuum Pad 3.125" x 2.000" square
VT-FP33X27 Replacement Foam Pad for Square Vacuum Pad 3.375"x 2.750" square
511-29-12F T7 Torx driver for 1/4" insert (straight angle insert holders only)
511-29-12E TORX SCREW M2.5 X 0.45 X (straight angle insert holders only)
T8S T8 Torx Tip Holding Screws
T15S T15 Torx Tip Holding Screws
MHS-375
Fixed Double Replaceable Insert Milling Head Screws for Large diameter milling Head
(3/8” insert)
MHS-250
Fixed Double Replaceable Insert Milling Head Screws for Small diameter milling Head
(1/4” insert)
S1032-250 BH375R1 and BH600R1 Tip Holder Looking Screw (10/32" X 1/4") Req. 2
S250-28-250 BH375WR1 Tip Holder Looking Screw 1/4"-28" X 1/4" Req. 2
S1032-437 TH1999 Adjusting Screw (10/32" X 7/16")
S1032-375 TH2000 Adjusting Screw (10/32" X 3/8")
S1032-500 TH2001 Adjusting Screw (10/32" X 1/2")
S1032-625 TH2002 Adjusting Screw (10/32" X 5/8")
S600-1570 TH2003 Adjusting Screw (6.00mm X 15.70mm)
S600-2015 TH2004 Adjusting Screw (6.00mm X 20.15mm)
M10X15X35
SG7 Rollover Fixture Hold down swivel Handle Zinc Handle 35mm (1.375") Long stud
(KHF-725)
500-13X2
SG8 Rollover Fixture Hold down swivel Handle Zinc Handle 2.000" Long stud (KHF-
162)
500-13X1375
SG7- SG8 Rollover Fixture Lock swivel Handle Zinc Handle 1.375" Long stud (KHF-
158)
ICC003
Insert, Indexable carbide, for Fixed milling heads - large size - for 1.562" and larger
cutters
ICC002
Insert, Indexable, carbide, for Fixed milling heads - small size - for 1.250" to 1.500"
cutters
