Machine Parts 5 SG9M Manual
S. NO. PART NO. DESCRIPTION QTY/M/C
1 430-820 COVER PAN 1
2
NCL -99
RISER 1
3 430-822 SCREW 4
4
430-822A WASHER 4
5 430-821 STOP PLATE 2
6 033-071 PLATE 1
7 430-830 VACCUM GAUGE 2.5” STD-B X ¼ NPT 1
8 430-831 N-22-SW (9301) 1
9 430-832 SV-3-M5 (6817) 1
10 430-837 QSS-6 (153158) 1
11 430-807 TOOL CABINET 1
12 430-816 TOOL TRAY 4
13 430-806 MOUNTING BRACKET 1
14 430-802 KNOB 1
15 430-817 CLAMP PIN 1
16 430-823 CLAMP LEVER 1
17
NC - 41
TABLE 1
18 VGS-804 WASHER 4
19 VGS-803 SCREW 4
20 430-811 PLAIN WASHER 11
21 430-810 LOCK WASHER 11
22 430-809 HEX. SCREW 3
23 430-812 HEX SCREW 7
24
430-801-1
CABINET ASSY 1
25 430-813 HEX SCREW 4
26 430-818 LEVELING BOLT 6
27 430-818A HEX NUT 6
28 430-819 PAD 6
29 430-825 HANDLE 2
30 430-827 MEGNET BLOCK 2
31 430-833 SPRING 4
32
430-834-I
ROD 1
33
430-834-II
ROD 1
34
430-835-I
FRAME WELDED SMALL 1
35
430-835-II
FRAME WELDED LARGE 1
36 430-838 SCREW 4
37 430-836 FOOT SWITCH MTG. BKT 2
38 430-814 SCREW 4
39 430-828 FOOT SWITCH ASSY 2
40 430-805 NUT 4
41 430-824 CHIP TRAY 1
42 430-835A PAD 4
43
430-835B-I
BUSH 4
44 430-826 TOOL BOARD 1
45 430-829 TOOL BOARD (R.H) 1
46 430-839 TOOL BOARD (L.H) 1
47 SUPPORT BRACKET 1
48 SCREW 2
49
NC-42
STOPPER PLATE 1
50 SCREW 2
