Machine Parts 15 SG9M Manual
S. NO. PART NO. DESCRIPTION QTY/M/C
1
430-913-B
HEAD SUPPORT LEFT 1
2 430-912 WASHER 2
3 430-938 A&B CLAMP BOLT LH & RH 1 EACH
4 430-970 HOLDER LEFT 1
5 430-901 BUSH 2
6 430-911 SCREW 1
7 430-906 SCREW 8
8 GRUB SCREW 2
9 VGS-959 SCREW 4
10 430-902 BEARING BUSH LEFT 1
11 430-957 PLATE 2
12 430-925 C’SINK SCREW 24
13 430-918 KNURLING COLLAR 4
14 430-917 SCREW 1/4"-20 4
15 430-916 PIN HOLDER 4
16 430-921 SPRING (SAME AS #100-057) 4
17 430-919 PLUNGER 4
18 430-915 PLATE 4
19 ------ -------- ---
20 430-936 SCREW 1/4”-20 X 3/4” LONG 2
21 430-940 FLAT 2
22 ------ ------ ---
23 430-914 GUIDE ROD 1
24 VGS-958 HOLDER RIGHT 1
25 430-907 BEARING BUSH RIGHT 1
26 430-934 SPACER 1
27 430-933 COLLAR 1
28 430-929 ARM 1
29 VGS-928 PIN 1
30 430-927 CLAMP 1
31 430-904 PIN 1
32 430-548 RETAINER RING 1
32A 430-550 THRUST BEARING 2
33 430-926 ADJUSTING SCREW 1
34 430-923 KNOB 1
35 430-924 PIN 2
36 430-922 PIVOT BLOCK 1
37
430-920-B
HEAD SUPPORT RIGHT 1
38 430-931 LOCK COLLAR SCREW 1
39 430-965 CLAMP PLATE 2
40 GRUB SCREW 2
41 430-964 CLAMP 2
42 430-949 PIVOT PIN 2
43 VGS-961 GUIDE PIN 4
44 VGS-967 SCREW 2
45 VGS-962 SCREW 2
46 VGS-963 PIN 2
47 430-941 HANDLE 2
48 430-939 T-NUT 2
49 430-944-1 HEAD SUPPORT 2
50 430-945 BAR 2
51 430-946 ROLL PIN 2
52 430-947 SWIVEL CLAMP 2
53 430-943 TUBE 2
54 430-942 KNOB 2
