RS PRO IPM 3600N - Page 11

3 Phase Power Analyser / EN
09/30/16 Version No. 00 8

Reactive Power Energy measurement (kVARh) :
Range Resolution
Reactive power
accuracy
Timer interval
Timer Accuracy
0.001 to 9.999kVARh
0.001kVARh
0.01 to 99.99kVARh
0.01kVARh
0.1 to 999.9kVARh
0.1kVARh
0.001 to 9.999MVARh
0.001MVARh
0.01 to 30.59MVARh
0.01MVARh
±1.0%rdg±20dgts
(10 to 299.9A)
±1.5%rdg±20dgts
(300 to 999.9A)
1 sec ±50ppm (25
°
C, 77
°
F)
• Measurement display : Display all reactive power consumption (sum of absolute values).

Harmonic measurement
Order Accuracy Harmonic Source
1 to 63
±3%THD
U1, U2, U3 > 10V
I1, I2, I3 > 10A

Waveform (possible only on a PC via a PC connection)
Select phase L1, L2 or L3.
Select Voltage and current waveform output.
