3 Phase Power Analyser / EN
33 09/30/16 Version No. 00
5-11 Voltage, Current Waveform and Harmonic Analyzer
These measurements can be performed via a PC using the software supplied. Please refer
to software manual (on the CD-ROM) for waveform and harmonic measurement.
5-12 Enable Auto Power Off Function
The instrument will automatically enter sleep mode after approximately 30 minutes to save
power consumption, when enable auto power function.
1. Enable auto power off procedure:
Press
key to turn off the instrument.
Press and hold down the “TIME” key, then press
key to
turn on the instrument, the auto
power function will be enabled, and the auto power off symbol will be appear.
2. Auto power off mode is disabled each time the instrument is turned on and is automatically
disabled as the follow modes:
ENERGY function is active.
Auto data logging function is active.
When linked to a PC.
