3 Phase Power Analyser / EN
09/30/16 Version No. 00 12
18. STOP key : Stop auto data logging function. Press “START” key to resume recording in
current data sets.
19. MEMORY key : Manual data memory control key. Press “MEMORY” key each time to store
one set of current display reading into the memory, the “M” symbol and the
memory address number is displayed, total memory size is 50 sets.
20. READ key : Read manual memory data control key.
21. POWER key : Display measured power value control key, the Pt123, Qt123 and St123
symbols will be displayed in cycles.
22. ENERGY key : Display total integrated power energy value control key.
23. KEY Lock key : Lock all the functions key, except
and keys, the “LOCK” symbol
is displayed.
24.
key : Power on-off control key.
25. MAG. key: Harmonic measurement control key.
Press “ MAG.” key to enter the voltage and current waveform harmonic
measurement mode, the harmonic order number “Hd:XX” and its measured value (V or
A), harmonic ratio (%), P, Q, S, PF values are displayed.
Press or key to scroll the harmonic order from “Hd:01” to “Hd:63”.
Press
↵
key to scroll the voltage or current harmonic for display.
Press ⊳ or key to scroll the U1, U2, U3 or I1, I2, I3 for display.
Press “ MAG.” key again to exit this mode.
