RS PRO IPM 3600N - Page 17

3 Phase Power Analyser / EN
09/30/16 Version No. 00 14
4.1
: Auto power off indication.
4.2
P : Harmonic active power measured display indicator.
P1 : Phase 1 active power measured display indicator.
P2 : Phase 2 active power measured display indicator.
P3 : Phase 3 active power measured display indicator.
Pt : Total active power measured display indicator and total active energy measured
display indicator.
4.3
Display value of Active Power
4.4
HOLD : Display hold mode.
4.5
REC MAX : Maximum recorded reading.
REC MIN : Minimum recorded reading.
REC : Recording mode indication and current reading.
4.6
KW : Active Power Unit: or KWh, MWh, active energy unit
4.7
Kvar : Reactive Power Unit or Kvarh, Mvarh reactive energy unit
4.8
Display of reactive Power
4.9
Q : Harmonic reactive power measured display indicator.
Q1 : Phase 1 reactive power measured display indicator.
Q2 : Phase 2 reactive power measured display indicator.
Q3 : Phase 3 reactive power measured display indicator.
Qt : Total reactive power measured display indicator and total reactive energy
measured display indicator.
4.10
DATA No.
××
: Last manual datalogged memory address number indication (01~50).
M : Manual datalogged indication, M displays one time store one sets data into the
memory.
R No.
××
: Recall manual datalogged address number indication, the memory data
displayed for read.
DATA M
××
: Auto datalogging indication, M disappears one time store one sets data
into the memory .
01 ~ 99: Maximum 99 memory blocks can be use.
FULL: Memory full indication, if exceed 99 memory blocks or micro SD
CARD is full used.
4.11
1P2W : Measure single-phase two-wire power line indicator.
1P3W : Measure single-phase three-wire power line indicator.
3P3W2M : Measure three-phase three-wire power line indicator.
3P3W3M: Measure three-phase three-wire power line using 3 power meter indicator.
3P4W : Measure three-phase four-wire power line indicator.
4.12
PF : Harmonic power factor measured display.
PF1 : Phase 1 power factor measured display.
PF2 : Phase 2 power factor measured display.
PF3 : Phase 3 power factor measured display.
PFt : Total power factor measured display.
4.13
Display value for Power Factor, Frequency & I4 current
4.14
LOCK : Keyboard lock indicator.
4.15
BT
: Low battery indicator.
