RS PRO IPM 3600N - Page 18

3 Phase Power Analyser / EN
15 09/30/16 Version No. 00
4.16
O
: Phase angle unit
ϕ : Phase angle display
4.17
Indicates current measurement from input “I4”
4.18
A : Unit of current
4.19
Hz : Unit of frequency
4.20
KVA : Apparent power unit or KVAh, MVAh : Apparent energy unit.
4.21
Display value of apparent power
4.22
S : Harmonic apparent power measured display indicator.
S1 : Phase 1 apparent power measured display indicator.
S2 : Phase 2 apparent power measured display indicator.
S3 : Phase 3 apparent power measured display indicator.
St : Total apparent power measured display indicator and total apparent energy
measured display indicator.
4.23
U1 : Indicates the display of voltage on phase 1(U1), THDR %, THDF % or Harmonic.
4.24
Y-M : Year and Month display indicator
4.25
Display of Voltage, Date (Year: Month), THDR % or Harmonic order number (Hd: 01 ~
Hd: 63)
4.26
U2 : Indicates the display of voltage on phase 2(U2), THDR %, THDF % or Harmonic.
4.27
D-h : Day and hour display indicator
4.28
Display of Voltage or Date (Day: hour) or THDR%
4.29
Display of the rotary field direction
4.30
U3 : indicates display of voltage on phase 3, THDR%, THDF% or Harmonic
4.31
m-s : minutes and seconds display indicator
4.32
Display of Voltage, Time (minutes: second) or THDR%
4.33
A, I3, % : units and indicator for phase 3 current, THDR%, THDF% or Harmonic
4.34
1000A : Current range indicator
4.35
Display of current, time or THDF%
4.36
A, I2, % : units and indicator for phase 2 current, THDR%, THDF% or Harmonic
4.37
Display of current, date/time or THDF%
4.38
1000V : Voltage range indicator
4.39
A, I1, % : units and indicator for phase 1 current, THDR%, THDF% or Harmonic
4.40
Display of current, date or THDF%
4.41
STOP : Indicates the stop time for energy calculation
4.42
THDF : Voltage or current Total Harmonic Distortion of a waveform to its Fundamental
indicator.
4.43
INTV : Indicates the Auto data logging interval time setting
4.44
STAR : Indicates the start time for energy calculation
4.45
THDR : Voltage or current Total Harmonic Distortion of a waveform to the waveform
RMS value indication.
4.46
TIME : Current data and time indicator
