3 Phase Power Analyser / EN
09/30/16 Version No. 00 24
5. Press “POWER” key to select between Phase 1(P1, Q1, S1, PF1), Phase 2 (P2, Q2, S2,
PF2) and total (Pt, Qt, St, PFt) measured values.
6. Frequency (Hz), Phase Angle (Θ) and Power Factor (pF) measurement:
Press “PFΘ” key to cycle shows the PF and Θ measured values.
Press “Hz I4” key to cycle shows the Hz and I4 measured values.
7. Voltage and Current THDR THDF measurement:
Please refer to section 4-1-12 “THD” key description.
8. Voltage and Current waveform harmonic measurement:
Please refer to section 4-1-25 “ MAG.” key description.
9. Power Maximum/Minimum measurement:
Please refer to section 4-1-10 “MAX” key description.
10. Energy measurement:
Press “ENERGY” key; the “Pt”, “Qt”, “St” and “PFt” or “φt” symbol are displayed and the
starting time of the energy measurement is displayed in the “STAR” line. The energy values
and the current time will be displayed during the energy measurement.
a). KW displays KWh
b). KVAR displays KVARh
c). KVA displays KVAh
Press “STOP” key to stop and hold the energy measurements. The “HOLD” symbol is
displayed and the final calculation time appears in the “STOP” line on the display.
Press “
↵
” key to exit the energy measurement mode and return to normal measurement
mode.
