Parts List VLT Pump Oil Lubrication Option.
ITEM
DESCRIPTION
ITEM
DESCRIPTION
076
TOP CASE
418
BOTTOM FLANGED COLUMN TUBE
078
INTERMEDIATE BOWL
418-1
FLANGED COLUMN TUBE
079
SUCTION BELL
429
FOUNDATION PLATE
082
DISCHARGE NOZZLE
479
PACKED TENSION RING
103
SUCTION BELL BUSHING
480
PACKING RING
167
PUMP SHAFT
486
"V" SEALING RING
176
IMPELLER
508
THRUST POT
201
IMPELLER WEAR RING
529
MOTOR HALF COUPLING
205
SUCTION BELL WEAR RING
530
PUMP HALF COUPLING
217
SHAFT BUSHING (SUCTION BELL)
532
ADJUSTING PLATE
217-1
SHAFT BUSHING (INTERMEDIATE
BOWL)
538
COUPLING SPACER
217-2
SHAFT BUSHING (COLUMN)
603
BASKET STRAINER
221
STUFFING BOX BUSHING
676
IMPELLER KEY
244
SAND CAP
676-1
PUMP HALF COUPLING KEY
256
IMPELLER SPLIT RING
678
GIB KEY
256-1
MOTOR COUPLING SPLIT RING
681
OIL TANK
264
ADAPTER
747
INTERMEDIATE BOWL O-RING
317
INTERMEDIATE BOWL BUSHING
747-1
TOP CASE O-RING
392
"T" COLUMN BUSHING (SHAFT SLEEVE)
747-2
COLUMN TUBE O-RING
396
COLUMN BUSHING (SHAFT SLEEVE)
747-3
BUSHING O-RING
397
TOP CASE BUSHING
747-4
PACKING RING O-RING OUTER DIAMETER
416
SHAFT SLEEVE
747-5
PACKING RING O-RING INNER DIAMETER
416-1
TOP SHAFT SLEEVE
950
RETAINER GUARD RING
