User
’
s Manual of RDC644XG Control System
SHENZHEN RUIDA TECHNOLOGY
4.1 Interface of Main Power Source CN0
4.2 Panel Signal-Cable Interface HMI
The panel signal-cable is a pin-to-pin cable, which is included in the factory shipper bill.
4.3 Udisk Interface
Udisk is a USB-AM interface. The controller may visit the u-disk by this interface.
4.4 PC-USB Interface
PC-USB is a USB-BM interface. The controller may communicate with PC by this
4.5 Ethernet Interface
Using this interface, the mainboard can communicate with PC by 10/100MHZ
Pin to Pin Ethernet parallel line is recommended.
24V power positive (input)
This control system employs single 24 power supply. For a certain
margin, it is suggested to select 24V/2A power. Besides, this system is
compatible with 36V power, that is to say, the 36V power of Motion
driver can directly be connected to this main power port of this system,
but generally it is not suggested to do so.
