RuiDa RDC644XG User Manual

User
’
s Manual of RDC644XG Control System
SHENZHEN RUIDA TECHNOLOGY
52
After the configuration parameters in the manufacturer parameters,
such as directional polarity, control mode, laser type and laser PWM
frequency, are modified, the system should be reset. Such a modification
can function upon the resetting of the system.
Enable parameters

Door Opening Protection: If this item is enabled, then the door
opening protection must be connected to the controller, or, the machine will not
run.

Whether to enable the blower: If using wind out port to control the
blower by the graph layer parameter, this item must be enabled, or, the wind
output is a signal for other using.
9.2 User parameters
（1）Cutting parameters(Only affect cutting arts)
 Idle Move Speed: this parameter decides the highest speed of all
non-lighting lines for the machine in the movement process.
 Idle Move Acceleration: it means the highest acceleration of all
non-lighting lines. Idle stroke speed and idle stroke acceleration can be set
higher to reduce the working time of the whole figure, but if they are set too high,
it may cause the jarring of track, so comprehensive consideration should be
given to the setting.

Idle Move Delay：If this parameter is zero, then after idle moving there
is no delay, or, there is delay and the speed will decrease to turn off speed.
 Turning Speed: it means the speed of turning at the acute-angle corner,
which is also the highest speed in the whole cutting process.
 Turning Acceleration: it means the acceleration of turning at the
acute-angle corner when cutting. If the two speeds are set too high, jarring will
happen to the turning; if set too low, it will influence the cutting speed. This
acceleration is the least value of the whole graph.
 Cutting Acceleration: it means the highest acceleration value in the
whole cutting process.
 Acc Factor: This parameter indicates how speedy the cutting
acceleration is changing.
 G0 Acc Factor: This parameter indicates how speedy the idle move
acceleration is changing.
 Speed Factor: This parameter indicates the cutting speed of the arc of
various curvatures.
● Key Setting: This is a button but not a parameter, this button is used to
recommend some experiential cutting parameters.
Prompt
