RuiDa RDC644XG User Manual

User
’
s Manual of RDC644XG Control System
SHENZHEN RUIDA TECHNOLOGY
43
8.3.13 Screen Origin
If the
“
Screen Origin
”
item is pressed, the system will show as below:
There are four entries to be selected: Top Left, Top Right, Bottom Left and Bottom Right. When
one is selected, the previewed graph on the screen would be enantiomorphous based on X or Y
direction.
This item is only used to preview the file on the screen, and it is no
meaning to the machine’s movement.
8.4 File Key
8.4.1 Memory File
On the main interface, if “File” key is pressed, it will show as below:
Figure 8.3-10
Caution
