moving, there can set a value to repay the interval of the two lines graph on Y
direction.
（4）Reset parameters

Reset Speed: it means the speed of X/Y-axle linkage reset to the origin.

X axle start-up reset(Auto home)

Y axle start-up reset(Auto home)

Z axle start-up reset(Auto home)

U axle start-up reset(Auto home)
You can select “Yes” or “No” in the field of the above four parameters, which is
used to confirm whether each axle can be reset on the startup.
（4）Go scale parameters

Go scale Mode: “Blanked Bordering” means idling to start border
preview; “Outputted Border Cutting” can manually cut off the well-processed
figure; “4-corner Dotting” means to emit the light at four corner points of the
frame to make a point and turn off light. The size and position of this figure can
be checked intuitively through the four points. The bordering speed is the speed
value set on the keyboard when the system is idle. For light output, its
minimum/maximum power is the corresponding value set on the keyboard when
the system is idle (The lasering power on the 4-corner dotting means the
well-set maximum power).

Go scale Blank: It means whether to extend a certain length outside
the actual frame of the figure on the preview/cutting of frame.
If the frame crosses the border, the interface will prompt it. If the Enter
key is pressed at this time, the system will cut the border at the
maximum/minimum coordinates first, and then border the figure. This
bordering can be given up.
（5）Other user parameters

Array Mode: Two-way array or one-way array can be selected.
Two-way array means the to-and-fro cutting of array in sequence; one-way array
means the cutting of array from one direction to another. On selecting one-way
array, the elements of each array are the same in action mode and completely
uniform in action fluency, which takes a little more time than two-way array.
Two-way array is the default option.

Back Position: The origin (the relative origin) and the machine’s
absolute origin can be selected. This parameter decides the parking position of
laser head after each work.

Focus Setting: it means the distance from the focal point of laser head
lens to Z-axle origin. When there is no automatic focusing function, this
parameter becomes invalid.

Backlash X: The X axes’ backlash, accurate to 1um.

Backlash Y: The Y axes’ backlash, accurate to 1um.
Prompt
