Ruijie Reyee RG-NBS Series User Manual

Web-based Configuration Guide Security
104
Table 7-1 Description of ACL Rule Configuration Parameters
Parameter
Description
ACL
Configuring ACL Rules Action
Block: If packets match this rule, the packets are denied.
Allow: If packets match this rule, the packets are permitted.
IP Protocol Number
Match IP protocol number The value ranges from 0 to 255. Check All to
match all IP protocols.
Src IP Address
Match the source IP address of the packet. Check All to match all source IP
addresses.
Dest IP Address
Match the destination IP address of the packet. Check All to match all
destination IP addresses
EtherType Value
Match Ethernet protocol type. The value range is 0x600~0xFFFF. Check All to
