3.4.3 Power Consumption @ 12 V DC
FM-Eco4 light S
FM-Eco4 light+ S
FM-Eco4+ S
FM-Eco4+ E S
Operating
Idle mode: 29.5 mA
Active mode: 46.4 mA
Sleep mode: 6.1 mA
Deep sleep mode: 4.1 mA
Operating while
charging battery
–
Idle mode: 100.1 mA
Active mode: 122.3 mA
Sleep mode: 74.1 mA
Deep sleep mode: 71.5 mA
3.4.4 Connectivity
FM-Eco4 light S
FM-Eco4 light+ S
FM-Eco4+ S
FM-Eco4+ E S
GSM
Modem: Quectel MC60
Antenna: Internal (Quad-band)
Frequency band: 850/900/1800/1900 MHz
GNSS (GPS, GLONASS)
module
Modem: Quectel MC60
Antenna: Internal or External
Augmentation systems: QZSS
Frequency: 1575.42 MHz (GPS); 1601.71 MHz (GLONASS)
Channels: 33 tracking, 99 acquisition, 210 PRN
Acquisition sensitivity: -149 dBm
Tracking sensitivity: -167 dBm
Reacquisition sensitivity: -161 dBm
Cold start duration: < 35 s
3.5 Interfaces
3.5.1 Power Supply
Pins
+BAT/VIN, GND/CHASSIS
Purpose
To power the device
Parameters
Voltage range: 6 – 31.5 V DC
3.5.2 Analog Inputs
Pins
AIN1, AIN2
Purpose
To monitor the values of various peripherals
Parameters
Voltage range: 0 – 30 V DC
Resolution: 12 bit
Applications
Various sensors
