RUPTELA FM-Eco4+ E S - Wiring Diagram (Regular Housing)

43
Correct
Incorrect
Correct
Incorrect
8.3.1 External GNSS Antenna Positioning
It is recommended to place the GNSS antenna behind the dashboard as close to the windshield as
possible and further away from the doors. It must be uncovered and facing up as shown in the
picture below.
Correct
Incorrect
Incorrect antenna placement may result in reduced tracking accuracy.
