O&M Manual –90E1720004
Section 8 Operation Page 43 of 52
Performing a Load Test or a No Load Test
1
Press the green test button on the face of the controller; this will bring up the exerciser\test
screen.
2
Press the grayed-out (disabled/inactive) <Xfer Load soft key> and a passcode dialog box
pops up.
3 Enter the level 1 passcode and press <enter>
4
The <Xfer Load soft key> is now enabled, and has turned orange. Press the orange <Xfer
Load soft key> to initiate load test.
5 The transfer switch times out and then transfers to Source 2.
6
To end the load test, press the <end soft key> and the transfer switch times out and
retransfers to Source 1.
NOTE
A NO-Load test is performed in a similar manner, by pressing the <noXfer soft key> on the
exerciser\test screen.
