Russelectric RTS03 Series User Manual

O&M Manual –90E1720004
Section 2 Introduction Page 8 of 52
Identification
Each Russelectric bypass-isolation transfer switch is identified by a unique combination of
model and serial numbers. These numbers, along with the electrical rating data, are provided on
a nameplate affixed to the bypass-isolation transfer switch and control system.
Write the necessary information in the spaces provided on the sample nameplate, to keep a
permanent and readily available record. This data is required to specifically identify your unit
when contacting Russelectric personnel.
RTS03 Model Numbering System
RTS 03-
Operation Type
A
Switch Type
BL
Operator
A
Ampere Rating
100
Poles
3
Terminal Type
M
Voltage
A
Enclosure Type
F
Enclosure Rating
1
Controller Type
RPTCS01
A = Automatic
M= Manual
BL = Load Break
BO = Overlapping
A = Single Operator
B = Dual Operator
C = Closed Transition
100 = 100A
150 = 150A
225 = 225A
260 = 260A
400 = 400A
600 = 600A
800 = 800A
1000 = 1000A
1200 = 1200A
1600 = 1600A
2000 = 2000A
2500 = 2500A
3000 =3000A
4000 = 4000A
2 = 2 Pole
3 = 3 Pole
4 = 4 Pole
A = 277/480V
B = 480V
C = 120/208V
D = 208V
E = 120/240V
F = 240V
G = 347/600V
H = 265/460V
I = 460V
K = 120V
M = Mechanical Lug
O = Other
C = Compression Lug
F = Freestanding
OV = Open Style
1 = Type 1
2 = Type 2
3 = Type 3
3R = Type 3R
4 = Type 4
4X = Type 4X
12 = Type 12
1G = Type 1 Gasketed
RPTCS01 = Level 1 Controller
RPTCS02 = Level 2 Controller
RPTCS03 = Level 3 Controller
RPTCS04 = Level 4 Controller
RPTCS05 = Level 5 Controller

Russelectric RTS03 Series Specifications

General

Brand	Russelectric
Model	RTS03 Series
Category	Switch
Language	English
