RYCO RY20C - OPERATION; Die Set Selection and Specifications

13MOBILE AND WORKSHOP SERIES OPERATION MANUALOctober 2018 | Version: v1-0
SELECTING THE DIE SETS
OPERATION
Refer to the latest RYCO Crimp Chart (available from www.RYCO.com.au) for the correct crimping specications.
Choose the appropriate size die to achieve the identied crimp diameter. The minimum crimp diameter is stamped on each die set.
Example: With die set No. RY32-10 and No. RY20-10 the minimum crimping diameter is 10 mm.
Use only original RYCO die sets in RYCO crimping machines.
RY32 Die Sets
For RY32C and RY32CB Crimpers
CRIMPING RANGE DIE LENGTH
Die Set
mm inch mm inch
RY32-07 7-10 0.276-0.394 55 2.16
RY32-10 10-12 0.394-0.472 55 2.16
RY32-12 12-14 0.472-0.551 55 2.16
RY32-14 14-16 0.551-0.630 55 2.16
RY32-16 16-19 0.630-0.748 55 2.16
RY32-19 19-22 0.748-0.866 55 2.16
RY32-22 22-26 0.866-1.024 70 2.16
RY32-26 26-30 1.024-1.181 70 2.16
RY32-30 30-34 1.181-1.339 70 2.95
RY32-34 34-39 1.339-1.535 75 2.95
RY32-39 39-45 1.535-1.772 75 2.95
RY32-45 45-51 1.772-2.008 90 3.55
RY32-51 51-57 2.008-2.244 90 3.55
RY32-57 57-63 2.244-2.480 120 4.72
RY32-63 63-69 2.4802.717 120 4.72
RY32-69 63-74 2.7172.913 120 4.72
RY32-74 74-80 2.9133.150 120 4.72
RY32-78 78-87 3.0713.425 120 4.72
CRIMPING RANGE DIE LENGTH
Die Set
mm inch mm inch
RY20-07 7-10 0.276-0.394 55 2.16
RY20-10 10-12 0.394-0.472 55 2.16
RY20-12 12-14 0.472-0.551 55 2.16
RY20-14 14-16 0.551-0.630 55 2.16
RY20-16 16-19 0.630-0.748 55 2.16
RY20-19 19-22 0.748-0.866 55 2.16
RY20-22 22-26 0.866-1.024 70 2.16
RY20-26 26-30 1.024-1.181 70 2.16
RY20-30 30-34 1.181-1.339 70 2.95
RY20-34 34-39 1.339-1.535 75 2.95
RY20-39 39-45 1.535-1.772 75 2.95
RY20-45 45-51 1.772-2.008 90 3.55
RY20-51 51-57 2.008-2.244 90 3.55
RY20-57 57-63 2.244-2.480 100 3.95
RY20 Die Sets
For RY20C and RY20CB Crimper
