RYCO RY20C - SPECIFICATIONS; RY20 C Model Specifications

18 MOBILE AND WORKSHOP SERIES OPERATION MANUAL
October 2018 | Version: v1-0
RY20C MOBILE  SPECIFICATIONS
ELECTRICAL PHYSICAL  CRIMPER WITH BASE DIMENSIONS
PART NUMBER VOLTAGE PHASE
MACHINE
CONTROL WIDTH DEPTH HEIGHT WEIGHT
*
mm inch mm inch mm inch kg lb
RY20C-12V 12 DC Digital 620 24.4 500
19.6
500 21.3 120 264
RY20C-24V 24 DC Digital 620 24.4 500 19.6 500 21.3 120 264
RY20C MOBILE  TECHNICAL INFORMATION
PART NUMBER MAX. HOSE SIZE CRIMPING RANGE DIAMETER MAX. DIE TRAVEL CRIMPING FORCE
inch mm inch mm inch kN tons
RY20C-12V 1.1/4 4-87 0.157-3.425 26 1.02 1700 190
RY20C-24V 1.1/4 4-87 0.157-3.425 26 1.02 1700 190
NOTE: *Without oil
RY20C
SPECIFICATIONS
500
