RYCO RY20C - TECHNICAL; Electrical Components RY20 CB;RY32 CB

25MOBILE AND WORKSHOP SERIES OPERATION MANUALOctober 2018 | Version: v1-0
TECHNICAL
ELECTRICAL SCHEME
Electrical Components List
RY20CB & RY32CB
Item Description Type Technical Data Standards Marking
Q1
Main disconnecter (switch type)
with undervoltage release trip
P1-32EASVB 250Vac, 30A
EN60947-1
EN60947-2
F1 Motor breaker
PKZM0-32
250Vac, 30A
EN60947-1
EN60947-2
GV2
F2 Circuit breaker
FAZ-2-S1
240/415V~
1Ax1P
EN60947-2
C60N C1A
KM1 Magnetic contactor
LC1D
Ui=660V
Ith=32A
EN60947
EN60947-4-1
CN-18
DILM 32D
TC1 Transformer control circuit supply
SL-9640
0.082kVA
1~, 380V/18V, 24V
IEC61558-1
IEC61558-2-4
SP-TBSW
M1 Pump motor BEFC-D
1.25kW 60Hz
1.8kW 50Hz
3.6kW 60Hz
3.6kW 50Hz
EN60034-1
U1
Power PCB+
Control PCB
32
20
24Vac, 18Vac,
15Vac, 10Vac
- -
SB1 Emergency Stop
RMQ
(M22-k01)
Ui=500V
Ith=4A,
Uimp=6kV
EN60947-5-1
SB2+
HL1
Push button (ON) with indicator
RMQ
(M22-k10+
M22-LED230)
Ui=500V
Ith=4A
Uimp=6kV
EN/IEC60947
SB3 Push button (OFF)
RMQ
(M22-k01+
M22-LED230)
Ui=500V
Ith=4A,
Uimp=6kV
EN/IEC60947
SA1 Selector
RMQ
(M22-k10)
Ui=500V
Ith=4A
Uimp=6kV
EN/IEC60947
SQ1 Touch-to-run switch XEN-L111
15A,
220V~
EN60947-1
S1 Foot switch YC-135
AC250V,
50/60Hz
3A
EN60947-1
EN60947-5-1
RP1 Potentiometer LHW 100 24Vdc EN61010-1
YV1 Solenoid valve
DG4V-5-8C-M-
U1-H-7-40
24Vdc VDE0580
YV2 Solenoid valve
DG4V-3-8C-M-
U1-H-7-52
24Vdc VDE0580
Terminal block
280
Ue=800V, 15A
IEC 947-7-1
EN60947
EN60127
BN-, BNH-
390
