RYCO RY20C - SPECIFICATIONS; RY32 C Model Specifications

19MOBILE AND WORKSHOP SERIES OPERATION MANUALOctober 2018 | Version: v1-0
RY32C
SPECIFICATIONS
RY32C MOBILE  SPECIFICATIONS
ELECTRICAL PHYSICAL  CRIMPER WITH BASE DIMENSIONS
PART NUMBER VOLTAGE PHASE
MACHINE
CONTROL WIDTH DEPTH HEIGHT WEIGHT
*
mm inch mm inch mm inch kg lb
RY32C-12V 12 DC Digital 620 24.4 500 19.6 540 21.3 160 352
RY32C-24V 24 DC Digital 620 24.4 500 19.6 540 21.3 160 352
RY32C MOBILE  TECHNICAL INFORMATION
PART NUMBER MAX. HOSE SIZE CRIMPING RANGE DIAMETER MAX. DIE TRAVEL CRIMPING FORCE
inch mm inch mm inch kN tons
RY32C-12V 2 4-87 0.157-3.425 32 1.26 2200
247
RY32C-24V 2 4-87 0.157-3.425 32 1.26 2200
247
NOTE: *Without oil
