32 MOBILE AND WORKSHOP SERIES OPERATION MANUAL
October 2018 | Version: v1-0
TECHNICAL
MASTER DIE MISALIGNMENT TROUBLESHOOTING
1. Master die detachment. Select manual mode on the
control panel and retract dies to the maximum
open position.
4. Conrm the main dies are in the home position
as shown.
3. Use the manual tools to position the die back in
the main track, as shown.
2. Grease application tool.
Manual die change tool.
