LRF 3013 Integrator Manual
Document number: TML 913655 ver A
Confidential & Proprietary Safran Vectronix AG – All rights reserved
3.3 First steps without LRF Interface Kit
LRF modules can be connected to your PC without an Interface box. In this case we recommend reading
this manual carefully before using the LRF module. Please be aware of the risk of wrong pin-connection
or destroying the module by applying overvoltage and other errors.
For the correct pin configuration see chapter 5.1
Power supply must not exceed the range of 4.5…16 V
The default Baud rate for LRF 3013 modules is 57’600 Bd
First range measurements can be performed by sending the software commands “>Md1<CR>” to the LRF
module. To achieve a valid range result, aim at targets of at least 30 m distance and ensure that you hit
the target and that no obstacles like closed windows are between the LRF and the target.
3.4 Checklist in case of problems with LRF modules
- Check if the Universal Interface battery is fully charged.
- Check if the COM-Port in the Terminal Software is the same as the COM-Port to
which the Universal Interface is connected.
- Ensure that power is supplied to the correct LRF module pins (see chapter 5.1).
- Check if Baudrate is set to 57’600.
