Safran LRF 3013 User Manual

LRF 3013 Integrator Manual
Document number: TML 913655 ver A
Public: 13.03.2017
Confidential & Proprietary  Safran Vectronix AG – All rights reserved
page: 29/36
Example
View in a terminal program
Legend
<>Iv<0D>
Prod: LRF-MB-ModC - 910994<0D>
Article Num.: 4294967295<0D>
Serial Num.: 0<0D>
uC FW: v00.04.00B00 - Dec 11 2013<0D>
DSP FW: 9.99 - 23/10/13<0D>
HW: 03-31-06-02<0D>
<
Commands sent to the module are in black
(hex values in blue). Characters sourced
by the module are in green (hex values in
red).
The hex value 0D is the carriage return.
6.2.4 Built-In Self Test
Table 3
Built-In Self Test
Command Input
Input
Description
>Tb1<CR>
It starts a self test sequence.
Command Output
Char Num.
Value
Description
1 to 5
BIST:
Message description string
6
<space>
Separation space
7 to 8
XX
Hex value representing tests’ results (see table below).
9
<CR>
End character
Example
Output
Description
BIST: F3<CR>
BIST: FF<CR>
5V and 7.5V power supplies failed their test.
All tests were successful.
View in a terminal program
Legend
<>Tb1<0D>
BIST: F7<0D>
<
Commands sent to the module are in black (hex values in
blue). Characters sourced by the module are in green (hex
values in red).
The hex value 0D is the carriage return.
