LRF 3013 Integrator Manual
Document number: TML 913655 ver A
Confidential & Proprietary Safran Vectronix AG – All rights reserved
1 General
The LRF 3013 (Vectronix article number 913461) is the smallest and most lightweight member of
Vectronix’ LRF Modules family. It combines unsurpassed range performance with outstanding
robustness. The rangefinder module is class 1 eye-safe according to IEC 60825 and ANSI Z136.1 (2007).
1.1 Main Elements and functions of the LRF Module
1.1.1 Main parts
a receiver, containing electronics and a receiver diode
a transmitter, containing electronics and a transmitter laser diode
a mainboard which manages all electronic elements and calculates the results
stable aluminum bench including optics
Figure 1: LRF 3013 main parts (top view)
Figure 2: LRF 3013 main parts (bottom view)
