94 VG5 Installation & Quick-Start Manual
Group F Options *
Function F3 DI-08, 16 Setup
F3-01
Digital Input
Selection
(DI Input)
0~7 1 0
0: (BCD 1%)
1: (BCD 0.1%)
2: (BCD 0.01%)
3: (BCD 1Hz)
4: (BCD 0.1Hz)
5: (BCD 0.01Hz)
6: BCD Special setting 5 digit
input, Binary 255/100%
(BCD (5DG) 0.01Hz)
7: (Binary)*
*Set value is displayed as
decimal.
x A A A A
Function F4 AO-08. 12
F4-01
Channel 1 Monitor
Selection
(AO Ch1 Select)
1~38 1 2
Analog Output option Channel 1
1: Frequency reference
2: Output frequency
3: Inverter output current
5: Motor speed
6: Output voltage
7: DC bus voltage
8: Output power
9: Torque reference (internal)
15: External terminal 13 input
voltage
16: External terminal 14 input
voltage
17: External terminal 16 input
voltage
18: Motor secondary current (Iq)
19: Motor excitation current (Id)
20: Primary frequency after SFS
21: Speed controller ASR input
22: Speed controller ASR output
23: Speed deviation
24: PID feedback
26: Voltage reference (Vq out-
put)
27: Voltage reference (Vd out
put)
32: ACR (q) Output
33: ACR (d) Output
36: PID Input
<1110>
37: PID Output <1110>
38: PID Reference <1110>
x A A A A
F4-02
Channel 1 Gain
(AO Ch1 Gain)
0.00~
2.50
0.01 1.00 — o A A A A
F4-03
Channel 2 Monitor
Selection
(AO Ch2 Select)
1~38 1 3
Analog Output option Channel 2
selection
(same as F4-01)
x A A A A
F4-04
Channel 2 Gain
(AO Ch2 Gain)
0.00~
2.50
0.01 0.50 — o A A A A
F4-05
<1110>
CH1 Output Bias
(AO Ch1 Bias)
–10.0
~10.0
0, 1 0.0 – o A A A A
F4-06
<1110>
CH2 Output Bias
–10.0
~10.0
0, 1 0.0 – o A A A A
* When access level is BASIC (A1-03), constant is not displayed unless the option is connected.
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
