MXS System Description and Installation Manual UM06945
© Sagetech Avionics 2022 Proprietary Confidential Page 30 of 56
Pin
Number
Signal
Direction
Signal Char.
11
Reserved
No Connect
-
12
Pin 12 -37 short.
Bi-Directional
Pass-through
13
5V
Power
5 VDC
14
Reserved for GPS-PPS
6
Input
TTL PPS
15
Maintenance Mode
7
Input
GND/Open
16
Weight-on-Wheels
Input
GND/Open
17
Com0-Mode
8
Input
GND/Open
18
GND
Power
Ground
19
Com0-422-RX+
8 9
Com0-232-RX
Input
RS-422 RX+
RS-232 RX
20
Com0-422-TX+
8 9
Com0-232-TX
Output
RS-422 TX+
RS-232 TX
21
Com1-422-RX+
8 9
Com1-232-RX
Input
RS-422 RX+
RS-232 RX
22
Com1-422-TX+
8 9
Com1-232-TX
Output
RS-422 TX+
RS-232 TX
23
Ethernet-TX+
9
Output
IEEE 802.3+
24
Ethernet-RX+
9
Input
IEEE 802.3+
25
GND
Power
Ground
26
GND
Power
Ground
27
Reserved
-
-
28
Reserved
-
-
29
Reserved
-
-
30
Reserved
-
-
31
Reserved
-
-
32
Reserved
-
-
33
Reserved
-
-
34
Reserved
-
-
35
Pin 10 - 35 short
Bi-Directional
Pass-through
6
MXS does not support GPS PPS, this is a future provision. Pin can be left floating (No Connect)
7
The transponder must be in maintenance mode for the Installation message to be received and processed, otherwise the
message is ignored.
8
RS-422 bus will be selected if pins are left unconnected. The pin must be grounded to select RS-232 bus. (See Table 6-2)
9
Transmit and receive are from the MXS perspective. Connect as appropriate. There must be at least one COM port
connected for control.
