MXS System Description and Installation Manual UM06945

Status Response Message

• Power-up BIT

• Continuous BIT

• Processor Test

• Flash Image CRC Valid

• Memory Test

• Calibrated data

• RF Loopback

• 53V Supply Failure

• ADC Ready

• Pressure Transducer Ready

• FPGA Ready

• RX Oscillator Locked

• TX Oscillator Locked

• Mutual Suppression Valid

• Temperature in Range

• Squitter Monitor

• Transmitter Duty Cycle in Range

• System Latency Check

• Transmit Power Failure

• GPS Position is invalid

• ICAO Address = All 1’s or 0’s

• Input Supply Voltage failure.
