43
Installation
0505
Interfaces
Options Connections
VHF Signal Cable Connection Connection Signal description Ships cable
Options Connector Designation box box 8 twisted pairs
15-pin D-sub male
In from VHF External conn. overall screen
pin 1
VDR+
X1-1 X2-1 pair no. 1
pin 2 VDR- X1-2 X2-2
pair no. 1
pin 3 AUX2 X1-3 X2-3
pair no. 2
pin 4 AUX2 NO X1-4 X2-4
pair no. 2
pin 5 AUX 1 X1-5 X2-5
pair no. 3
pin 6 AUX 1 NO X1-6 X2-6
pair no. 3
pin 7 int_Speaker + X1-7 X2-7
pair no. 4
pin 8 int_Speaker - X1-8 X2-8
pair no. 4
pin 9 DSC CALL X1-9 X2-9
pair no. 5
pin 10 DSC CALL NO X1-10 X2-10
pair no. 5
pin 11 GND X1-11 X2-11 Equipment ground
pair no. 8
pin 12 NMEA + X1-12 X2-12
pair no. 6
pin 13 NMEA - X1-13 X2-13
pair no. 6
pin 14 DSC ALARM X1-14 X2-14 pair no. 7
pin 15 DSC ALARM NO X1-15 X2-15 pair no. 7
spare pair no. 8
Note 1: Relay contact ratings (resistive load) Max. switched power: 30W or 60VA
Max. switched current: 1.0A
Max. switched voltage: 150VDC or 125VAC
in accordance with IEC61162-1
Mixed Rx/Tx audio output for recording.
Galvanically isolated, balanced signal,
0dBm/600Ω
VHF internal speaker output, rating 8ohm, 6W
max.
Relay contact closing on event pre-defined
through service programming (see note 1)
Relay contact closing on event pre-defined
through service programming (see note 1)
NMEA data input from external position
sensor (note 2)
Relay contact closing on incoming Distress
alert (see note 1)
Relay contact closing on incoming DSC call
(see note 1)
Note 2: Following NMEA sentences are supported: GLL, RMC, ZDA, GGA, VTG, GNS
SPARC Connections
VHF Signal Cable Connection box Connection box Connection box Connection box Signal description Ships cable
SPARC Connector Designation p/n In from VHF Out to CU1 or Out to CU2 or Alarm Panel 8 twisted pairs
15-pin D-sub female
56.114 Extension box overall screen
pin 1
12.5VDC+
X3-1 X4-1 X5-1 X6-1 pair no. 8
pin 2 DATA_+ X3-2 X4-2 X5-2 X6-2
pair no. 1
pin 3 DATA_- X3-3 X4-3 X5-3 X6-3
pair no. 1
pin 4 TX_AF+ X3-4 X4-4 X5-4 X6-4
pair no. 2
pin 5 TX_AF- X3-5 X4-5 X5-5 X6-5
pair no. 2
pin 6 GND X3-6 X4-6 X5-6 X6-6 Equipment ground
pair no. 6
pin 7 12.5VDC+ X3-7 X4-7 X5-7 X6-7
pair no. 6
pin 8 RX_AF+ X3-8 X4-8 X5-8 X6-8
pair no. 3
pin 9 RX_AF- X3-9 X4-9 X5-9 X6-9
pair no. 3
pin 10 12.5VDC+ X3-10 X4-10 X5-10 X6-10
pair no. 7
pin 11 EXT.Speaker + X3-11 X4-11 X5-11 X6-11
pair no. 4
pin 12 EXT.Speaker - X3-12 X4-12 X5-12 X6-12
pair no. 4
pin 13 GND X3-13 X4-13 X5-13 X6-13 System ground
pair no. 7
pin 14 Lineout + X3-14 X4-14 X5-14 X6-14 pair no. 5
pin 15 Lineout - X3-15 X4-15 X5-15 X6-15 pair no. 5
spare
pair no. 8
E XT LS X8-1 X9-1
E XT LS X8-2 X9-2
NOTE:
In case of connecting CU1 and/or CU2 directly to Connection Box, i.e. not utilizing Extension Box for each CU, jumpers
J1/J2 and/or J3/J4 must be cut to disconnect VHF Ext. Speaker output from these terminals and make available the CU Ext.
Loudspeaker connection and provide the CU1/CU2 External speaker connection respectively.
Mixed Rx/Tx audio line
output, xxmV/47k
External speaker output,
rating 8Ω/6W max. (
see
NOTE
)
SPARC-bus Data
SPARC-bus Rx audio
SPARC-bus Tx audio
VHF radio external speaker
output, 8Ω/6W min.
