8000m Series
- 12 -
Input & Output Characteristics
Start Frequency 0.01~10Hz
Rated Input Voltage
220V/380V ± 15%
Rated Input
Frequency
50/60Hz,fluctuation range:±5%
Frequency Reference
Resolution
Analog signals: max. frequency × 0.1%; Digital setting:0.01Hz
Output Voltage 0: rated input voltage
Output Frequency
Range
0.00~600Hz
Peripheral I/O Characteristics
Digital Input
Terminals
4 inputs (programmable)
Analog Input
Terminals
AVI: 0~10V or 0/4～20mA (Jumper 10)
Relay Output 1 relay output (programmable)
Open Collector
Output
1 channel (programmable)
Analog Output FM: 0~10V; 0/4~20mA (Jumper 12)
Basic Functions
Operating Command
Channels
Three channels: keyboard, control input terminals, serial
communication interface. These channels can be switched by
several methods.
Frequency
References
7 references including panel potential meter, UP/DOWN key digital
setting, communication and PID control, etc.
Auxiliary Frequency
Reference
1 auxiliary frequency references, can be used in frequency
combination or adjustment.
Multi-step speed &
Simple PLC Function
14 steps multi-step speed control can be carried out by control input
terminals or built-in simple PLC function.
Built-in PID Function
Closed loop control of system variables such as pressure, speed or
temperature can be carried out by a built-in Proportional + Integral
+ Derivative (PID) controller.
