8000m Series
- 142 -
Communication setting
2000H
Communication Setting Range
(-10000~10000)
Note: the communication setting is the
percentage of the relative value
(-100.00%~100.00%). If it is set as
frequency source, the value is the
ercentage of the maximum frequency.
If it is set as PID (preset value or
feedback value), the value is the
percentage of the PID.
W/R
2001H
PID setting，
Range: 0~1000，1000 means100.0%
W/R
2002H
PID fedback，
Range: 0~1000，1000 means100.0%
W/R
2003H
Setting value of torque
Range: -1000~1000
1000 means 100.0%
W/R
2004H
Setting value of upper limit frequency
(0~Fmax)
W/R
VFD Status
data
3000H Output frequency R
3001H Reference frequency R
3002H DC Bus voltage R
3003H Output voltage R
3004H Output current R
3005H Rotation speed R
3006H Output power R
3007H Output torque R
3008H PID preset value R
3009H PID feedback value R
300AH Input terminal status R
