SAJ 8000m Series User Manual

8000m Series
- 21 -
Inverter Model
Circuit
Breaker
(MCCB) (A)
Recommend
ed Contactor
(A)
Conducting
Wire of Main
Circuit at the
Input Side
(mm
2
)
Conducting
Wire of Main
Circuit at the
Input Side
(mm
2
)
Conducting
Wire of
Control
Circuit
(mm
2
)
8000m-2SR75GB 16 10 2.5 2.5 1.0
8000m-2SR75GB 16 10 2.5 2.5 1.0
8000m-2S1R5GB 20 16 4.0 2.5 1.0
8000m-2S2R2GB 32 20 6.0 4.0 1.0
8000m-4TR75GB 10 10 2.5 2.5 1.0
8000m-4T1R5GB 16 10 2.5 2.5 1.0
8000m-4T2R2GB 16 10 2.5 2.5 1.0
2.1.7 Table of Recommended Reactor
Inverter Model
AC Reactor at the Input
Side
AC Reactor at the output
Side
Voltage
Current (A)
Inductance
(mH)
Current (A)
Inductance
(mH)
8000m-2SR75GB 2 7 2 7
220V
8000m-2SR75GB 2 7 2 7
8000m-2S1R5GB 5 3.8 5 3.8
8000m-2S2R2GB 7.5 2.5 7.5 2.5
8000m-4TR75GB 2 7 2 3
380V
8000m-4T1R5GB 5 3.8 5 1.5
8000m-4T2R2GB 7 2.5 7 1
