SAJ 8000m Series

8000m Series
- 43 -
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modifica-
tion Type
F7.01~F
7.03
Reserved
F7.04
RUN/STOP key
stop function
0:Only valid for keypad setting
1:Valid for both keypad setting
and terminals setting
2:Valid for both keypad setting
and communication interface
setting
3:Valid for all control mode
0 ○
F7.05 Reserved
F7.06
Running status
display selection 1
0~0xFFFF
BIT0:Running frequency
BIT1:Setting frequency
BIT2:DC bus voltage
BIT3:Output voltage
BIT4:Output current
BIT5:Running speed
BIT6:Linear speed
BIT7:Reserved
BIT8:Reserved
BIT9:PID setting value
BIT10:PID feedback value
BIT11:Input terminals status
BIT12:Output terminals status
BIT13:Reserved
BIT14:Counter value
BIT15:Current step of
multi-step
speed and PLC
35 ○
