8000m Series
- 84 -
disconnected, it will go back to the frequency of
UP/DOWN setting.
33 Reserved
34 Length counting input
Length counting by the input signal. If the signal
of counting input is a pulse signal, it is needed to
transfer it into a discrete signal by a relay(the
frequency of input signal should be lower than
200Hz)
35 Length counting clear up Clear up the present values of counting meter
36
Control command source
switching
When the terminal is defined as this function, and
when terminal input is switching, it can select
command source between keypad command and
terminal command.
37 Terminal input delay output
When the terminal is defined as this function, the
close time of this terminal exceeds the setting
value of F8.21, and the function of the digital
output such as relay is defined as 16, the digital
output will be activated as closed, or it will
disconnect
38 Reserved
