SAJ 8000m Series User Manual

8000m Series
- 97 -
F6.17
Output comparison value
X1
Factory Setting 0
Setting Options 0~65535
F6.18
Output comparison value
X2
Factory Setting 0
Setting Options 0~65535
This two parameters is used to set the comparison value of user-defined output.
The following is an example of user-defined output:
1. When the setting frequency is required to be greater than or equal to 20.00HZ, the
relay is closed;
Set the parameters as follows: F6.02 = 14, F6.28 = 1, F6.15 = 11, F6.16 = 0, F6.31 =
2000;
2. When the bus voltage is require to be less than or equal to 500.0V, the relay is
closed; In order to avoid relay operates frequently when the detection voltage
fluctuate ±5V at 500.0V, it requires to process the dead intervalwithinthe range of
(500.0-5.0) - (500.0 + 5.0) .
Set the parameters as follows: F6.02 = 41, F6.28 = 2, F6.29 = 01, F6.30 = 50, F6.31
= 5000;
3. When the AC drive is reversed, the relay is closed:
Set the parameters as follows: F6.02 = 41, F6.28 = 5, F6.29 = 14, F6.31 = 8, F6.32 =
8;
4. When AI1 input is greater than 3.00V and less than or equal to 6.00V, the relay is
closed:
Set the parameters as follows: F6.02 = 41, F6.28 = 13, F6.29 = 13, F6.31 = 300,
F6.32 = 600
