SAJ CHS2 Series User Manual

CHS2 Series
11
12
3.3 Overview of Products
Figure 3.2
Dimensions of inverter
3.4 Terminals Description
Figure 3.3
Battery module interface
Figure 3.4
Battery control unit interface
Table 3.1
Waterproof connector wiring identification
A
220V input from CH2
B
High voltage box and CH2 power line
C
CAN communication with CH2 and parallel machine
D
Parallel 220V AC output
E
Parallel DC positive input
F
Parallel DC negative input
G
Parallel DC negative output
