COMMISSIONING
6.1 Start Up and Shut Down the Energy Storage System
6.1.1 Start Up
Step 1: Turn ON the DC switch on the inverter.
Step 2: Turn on the AC Circuit Breaker.
Step 3: Rotate the Main Switch to ON position.
Step 4: Press and hold the START switch for 3 seconds until the LED light flashes.
Step 5: If the grid is disconnected, press the START button following step 4.
Note: If the Main Switch suddenly trips while the machine is running, it is required to reset the Main Switch
and re-rotate the Main Switch to ON position.
6.1.2 Shut Down
Step 1: Turn off the AC Circuit Breaker.
Step 2: Rotate the Main Switch to OFF position.
Figure 6.1
Circuit breaker of inverter
