SAJ CHS2 Series User Manual

CHS2 Series
59
60
6.10 Setting Reactive Power Control
(For Australia)
6.10.1 Setup Fixed Power Factor Mode & Fixed Reactive Power Mode
Fixed Power Factor Mode
Step 1: Select Power Adjustment and enter password “201561”.
Step 2: Select Capacitive Power Factor or Inductive Power Factor according to your local grid regulation.
The power factor range is from 0.8 leading ~ 0.8 lagging.
Fixed Reactive Power Mode
Step 1: Select Inductive Adjustment Var or Capacitive Var according to your local grid regulation. The
power range is from -60%Pn ~ 60%Pn.
6.10.2 Setup V-Watt and Volt-Var Mode
This inverter complies with AS/NZS 4777.2: 2020 for power quality response modes. The inverter
satisfies different regions of DNSPs' grid connection rules requirements for volt-watt and volt-var
Settings. e.g.: AS4777 series setting as below Fig 6.2&6.3.
